RadioLink AT9S Pro 10Ch/12Ch Radio System

生產商: RadioLink
Excellent value 2.4Ghz RC transmitter for both Air and Land, adopted DSSS & FHSS spread spectrum hopping technology. Radiolink 2019 AT9S Pro Version TX 10/12CH RC Transmitter Radio Controller Support...

有現貨

HK$999.00


Excellent value 2.4Ghz RC transmitter for both Air and Land, adopted DSSS & FHSS spread spectrum hopping technology.
Radiolink 2019 AT9S Pro Version TX 10/12CH RC Transmitter Radio Controller Support TBS Crossfire CRSF Protocols for Racing Drone, Quadcopter, Fixed Wing, Helicopter, Car Vehicles and more (Mode 1/2)
DSSS* and FHSS* which reduce overall signal interference and allow the AT9S Pro to produce a highly constant and stable transmission signal present on all 12 channels.
Setting simplicity, Excellent Anti-interference, Real-time Telemetry, USB upgrade, Voltage Protection, 3ms fast response for 10/12 channels, outstanding range over 2.4 miles(4km) (actual control distance is according the local environment).

Features
  • Excellent Anti-interference: The rc transmitter with DSSS&FHSS working synchronously to keep the excellent anti-interference performance, only 3ms for10 channels response.

  • CRSF Protocol Supported: On the basis of the RadioLink unique communication technology of DSSS and FHSS, CRSF protocol from Blacksheep is added. Compatible with TBS Crossfire 915 module.

  • Compatible with SBUS, PPM, PWM and CRSF: With DSSS&FHSS protocol, SBUS, PPM and PWM can operate simultaneously for seamless user control. With CRSF protocol.

  • Real-time Information: When PRM-03 module works with flight controller, model voltage, speed, climb, throttle, longitude, latitude, altitude, GPS, RSSI, flight mode, yaw, roll, pitch and distance are displayed on the LCD screen display.

  • Adapts to Most of Types of Aircraft: Easy to understand user software makes quick work of changing aircraft types, Rotary Wing, Fixed Wing, Glider, Multicopter, Car, Boat, Robot.

  • USB Based Update: Transmitter is easily updated with the latest firmware by USB cable to connect PC.

  • Voltage Protection System: RadioLink’s voltage protection software ensures vital components are protected from a reverse polarity connection.

  • Simple Setting Humanized: Menu is designed applicable to both beginners and skilled person, only need takes 1 second to bind.

  • Support for Universal Battery: JST 2Pin connector supports multiple type batteries: 8 pcs AA or 2s-4s LiPo battery. (Not included batteries) A 3s 1800mAh liPo battery can work more than 12 hours.










Specifications
  • Channels: 10ch/12ch
  • Mode: Mode 1 or Mode 2
  • Signal: SBUS/PWM/PPM/CRSF
  • Frequency: 2.4GHz ISM bands (2400MHz to 2483.5MHz)
  • Channel Bandswidth: 5.0 MHz
  • Spread Spectrum: DSSS&FHSS/CRSF
  • Modulation Mode:QPSK
  • Adjacent Channel rejection: >38dbm
  • Transmission Power: DSSS & FHSS <100mW(20dbm)
    CRSF: 10mW/25mW/100mW/500mW/1W/2W(Optional)
  • Operating Current: DSSS&FHSS < 90mA@12V
  • CRSF Depends on the transmission power selecte
  • Operating Voltage: 7.4~18.0V
  • 4096 Section Precision
  • Screen: 2.8 inches 16 colorful screen, 240*320 pixels
  • Channel: 12 channels , 5-12 channels are customized
  • Size: AT9S Pro 183*100*193mm
  • Weight: 0.88kg
  • Control Range: 4 kilometers in the air (Maximum range is tested in an unobstructed area free of interference)
  • Compatible receivers: RadioLink R12DSM, R12DS, R9DS, R6DS,R6DSM, Receiver from BLACKSHEEP (CRSF Protocol)
In the box :
  • 1x RadioLink AT9S Pro 10-Ch 2.4GHz Transmitter
  • 1x English Manual in CD-ROM
  • 1x TBS Crossfire Connect Cable
  • 1x Neckstrap


Useful Items :




      Product Status : In-Stock
